The documents on this page are scans of original documents, most loaned to me by other collectors. Printed information on Watkins Johnson equipment is often very scarce. Catalogs for older equipment like Communications Electronics, Inc. and Nems Clarke are even harder to find.

If you have any original catalogs you'd be willing to loan for inclusion please contact me.

1968 Communications Electronics

CEI became a division of WJ in late 1967. The CEI logo on the cover picture of the Executive Blvd. building in Rockville, MD was replaced in Feb. 1969.

1970 Watkin-Johnson (May - early edition)

The CEI logo has been replaced by the WJ logo throughout this catalog. The 112 microwave receiver, the Pan-Man RS-160 and the RS-158 are new.

1970 Watkins Johnson (late edition)

This catalog combines listings for products from the CEI division on the East Coast with systems and antennas from the West Coast

1971 Watkins Johnson

Twice the size of the late 1970 catalog, this catalog is much slicker and contains many West Coast products like the WJ-1140 and WJ-10xx tuner series.

1978 Watkins Johnson

Features new digitally controlled VHF, UHF and microwave receivers like the WJ-8622, WJ-9023A and WJ-9025.

1982 Watkins Johnson

Product line straddles two eras. Has the older receivers and systems like the WJ-8888B and the RS-160, but also includes the WJ-9040 and the massive WJ-8940B.

1988 Watkins Johnson

Contains many classics like the WJ-8718A HF radio, the WJ-9040 system and great pieces like the WJ-9195C RASP unit. It also contains the first WJ-8607 miniceptor.

1989 Watkins-Johnson

Most notable change from 1988 is the miniceptor line expands slightly.

1990 Watkins-Johnson Reconnaissance Electronics Technology Division

This is primarily a WJ West Coast catalog with microwave surveillance and test equipment.

1993 Watkins Johnson

The most common catalog. I seen copies for sale at hamfests. Contains an expanded miniceptor line. Lists the WJ-8617 radios, which were produced for a long time.

1966 Communications Electronics, Inc. catalog

This is the earliest document I have and it is only a photocopy missing the cover. This is nuvistor based early equipment like the 903, 701, 501 and RS-125

1997 Watkins Johnson

This is an electronic version of a long form catalog. Long form catalogs were collections of technical data sheets for the individual products. This catalog contains many items still current in the DRS WJ catalog.

Catalogs came in three types -
Short form catalogs were booklets with brief descriptions of many radios and ancillary equipment in current production.
Long form catalogs were ring binders of data sheets with much more extensive information on the individual pieces of equipment. Original long form catalogs are especially scarce.
Electronic catalogs were distributed on compact discs. Electronic catalogs were sometimes produced in conjunction with symposium presentations.

Current Watkins Johnson radios are still produced by DRS Technologies. The model numbers still start with "WJ " although the DRS website makes scarce mention of the name Watkins Johnson .
